SSD recovery without guesswork

How to Recover Data from Failed SSD?

A failed SSD needs a cautious approach. Start by deciding whether the problem is logical, connection-related, or a true hardware fault.

By Taptu Newsroom Editorial Team Published · Updated
Quick answer

Stop using the SSD immediately. If it remains visible with the correct capacity, create a byte-to-byte image with Disk Drill, scan the image, then save recovered files elsewhere. If the SSD is missing, unstable, unusually hot, or listed with the wrong capacity, skip software plus contact a recovery lab.

!

Do not initialize, format, run CHKDSK, reinstall the operating system, or save recovered files onto the failed SSD. Deleted SSD data may also be cleared by TRIM, so quick action helps but cannot guarantee recovery.

Jump to methods Compare methods
★ Editorial pick ★ 4.4 / 5

Image and Scan a Visible Failed SSD → Disk Drill

Creates byte-to-byte backups, scans disk images, previews recoverable files, plus runs on Windows or macOS

✓ Windows & macOS ✓ Free scan and preview ✓ Byte-to-byte backup
Try the free scan →

When Software Cannot Recover a Failed SSD

Recovery software needs the operating system to receive readable sectors from the SSD. It cannot repair a dead controller, damaged power circuit, inaccessible NAND chips, or firmware that prevents the device from identifying correctly.

TRIM creates a second limit. If the SSD has already cleared deleted blocks, no app can reconstruct those bytes. A scan may still find older filenames or folder records, but that does not mean the file contents remain intact.

How to Read Common Failed SSD Symptoms

An SSD that appears at the right capacity but has a damaged partition is a reasonable software-recovery candidate. One that works through a different cable likely had a connection problem. An SSD showing zero bytes, a strange model name, constant disconnects, or no BIOS entry points toward controller, firmware, power, or NAND trouble.

Choose the Right Failed SSD Recovery Method

Match the method to how the SSD behaves before doing anything that writes to it.

Method Best for Time Success rate
1. Image the SSD, Then Scan It With Disk Drill TRY FIRST Visible SSDs with stable reads ~30 min+ ● 70%
2. Scan the Stable SSD Directly Logical damage on a stable device ~20 min+ ● 62%
3. Restore the Files From a Backup Previously backed-up or synced files ~10 min ● 95%
4. Test the SSD Through Another Connection Cable, enclosure, port, or power faults ~15 min ● 45%
5. Send the SSD to a Recovery Lab Invisible or physically failed SSDs ~3–15 days ● 75%

Top 5 Methods to Recover Data From a Failed SSD

01

Image the SSD, Then Scan It With Disk Drill

Best first move when the failed SSD still appears with the correct capacity

~30 min+
Difficulty Easy
You need Disk Drill plus a healthy destination drive
Works for Windows, Mac

If the SSD remains visible plus reads without repeated disconnects, make a byte-to-byte image before searching for files. Disk Drill can scan the image instead of repeatedly stressing the original device.

  1. Stop using the failed SSD. Do not format, initialize, repair, defragment, or install software on it.
  2. Connect a healthy drive with free space at least equal to the SSD's full capacity.
  3. Install Disk Drill on the healthy system drive, not the failed SSD.
  4. Open Byte-to-byte Backup, select the failed SSD, then save its image to the healthy drive.
  5. Load the completed image into Disk Drill, choose Search for lost data, then let every relevant scan finish.
  6. Preview several important files. Select usable results, then recover them to another healthy drive.
Disk Drill Review ↗
i Stop imaging if the SSD vanishes, freezes the computer, becomes unusually hot, or reports rapidly increasing read errors.
Visit Disk Drill
02

Scan the Stable SSD Directly

A quicker option for logical failure when imaging space is unavailable

~20 min+
Difficulty Easy
You need Disk Drill plus separate recovery storage
Works for Windows, Mac

A direct scan can find files after partition damage, accidental formatting, or a corrupted file system. Use this route only if the SSD stays connected reliably plus shows its expected size.

  1. Connect the SSD as a secondary device through a known-good internal port or compatible enclosure.
  2. Confirm that Disk Management on Windows or Disk Utility on macOS lists the SSD. Reject any prompt to initialize or erase it.
  3. Launch Disk Drill, select the whole physical SSD rather than only a damaged volume, then click Search for lost data.
  4. Allow the scan to complete. Use file type, date, size, plus search filters to narrow the results.
  5. Preview a sample from each critical folder before paying for recovery or copying a large batch.
  6. Recover selected files to a different SSD, hard drive, or network location.
i Direct scanning creates more reads than scanning an image, so it is a poor choice for an unstable device.
03

Restore the Files From a Backup

Safest when the SSD holds synced or previously backed-up data

~10 min
Difficulty Easy
You need Backup drive or cloud account
Works for Windows, Mac, Linux

A backup avoids nearly every hardware risk. Check more than the obvious place since files may exist in version history, another computer, email attachments, or a cloud recycle bin.

  1. Leave the failed SSD disconnected while checking backup sources.
  2. Review File History, Windows Backup, Time Machine, NAS snapshots, plus any disk-image archives.
  3. Sign in to cloud storage from a healthy computer, then inspect deleted-item folders plus version history.
  4. Check other computers, phones, camera cards, shared folders, plus sent email for secondary copies.
  5. Restore a small test folder to a healthy drive, open its files, then restore the remaining data.
  6. Keep the recovered copy separate until the replacement SSD has passed health checks.
i A slightly older working backup is usually better than risking the only copy on a deteriorating SSD.
04

Test the SSD Through Another Connection

Useful when an enclosure, cable, port, or power path may be the real failure

~15 min
Difficulty Moderate
You need Compatible adapter, port, or second computer
Works for SATA, M.2 SATA, NVMe

An SSD that disappears is not always internally dead. A bad USB bridge, loose SATA lead, incompatible M.2 enclosure, or weak power source can prevent a healthy controller from showing up.

  1. Identify the exact interface. M.2 SATA plus M.2 NVMe drives require different enclosure support despite looking similar.
  2. Power down the computer before reseating an internal SSD or replacing a SATA cable.
  3. Try one known-good port, cable, enclosure, or compatible computer. Avoid dozens of repeated power cycles.
  4. Check BIOS or UEFI first, then Disk Management or Disk Utility. Do not initialize the disk if it appears as unknown or unallocated.
  5. If the SSD becomes stable with the correct capacity, return to Method 1 to create an image immediately.
  6. If it remains absent, shows zero capacity, reports the wrong model, or repeatedly disconnects, stop DIY testing.
i Never open an SSD casing, heat the board, freeze the device, or attempt random firmware commands.
05

Send the SSD to a Recovery Lab

The sensible route for controller, firmware, electrical, or NAND failure

~3–15 days
Difficulty Easy to arrange
You need A qualified SSD recovery lab
Works for Physically failed SSDs

Software cannot scan a device that never exposes readable storage. A specialist may need controller-level access, donor components, firmware work, or direct NAND recovery, though modern encryption can limit what is possible.

  1. Disconnect the SSD once physical failure seems likely. Continued power cycling can make an intermittent fault permanent.
  2. Write down the model, capacity, computer type, failure symptoms, encryption status, plus the last event before failure.
  3. Contact two or three labs that specifically handle SSD firmware plus NAND recovery, not only hard drives.
  4. Ask whether diagnosis is free, whether approval is required before work, plus what happens if no usable data is recovered.
  5. Pack the bare SSD in an antistatic bag with firm padding. Use tracked shipping plus retain its serial number.
  6. When the lab supplies a file list or sample, confirm that your highest-priority folders are included before approving the final recovery.
i For irreplaceable business records, legal evidence, or the only copy of family media, move this method to the top.

Which Failed SSD Recovery Method Should You Use?

Creating an image with Disk Drill is the best first move when the SSD remains visible, reports its correct capacity, plus reads consistently. Scan the image rather than repeatedly scanning the original. A backup is safer if one exists, while connection tests make sense for a drive that is not detected through one particular adapter.

If the SSD vanishes, overheats, freezes the computer, or reports incorrect details, stop. A recovery lab has a better chance than another round of DIY software.

Top pick Disk Drill
Make one careful diagnosis, then choose a path. Repeated scans, repairs, plus power cycles rarely improve a failing SSD.

Failed SSD Recovery Questions, Answered

How do I recover data from a failed SSD without making it worse?
Stop using the drive right away, then clone it before trying any file recovery steps. If the SSD still appears in Disk Management, a sector-by-sector image is the safest first move.
Can I recover files from an SSD that no longer shows up in Windows?
Sometimes, yes, but it depends on whether the controller still responds at all. Check another cable, another port, then another computer before assuming the SSD is dead.
Is SSD data recovery harder than HDD recovery?
Usually yes, because SSDs can fail at the controller, firmware, or NAND level with less warning. TRIM also makes deleted file recovery much less reliable than on a hard drive.
What should I do first when my SSD fails?
Disconnect it, then avoid reinstalling Windows, running chkdsk, or copying new files onto it. Your first goal is to preserve the current state, not fix the drive in place.
Can I use free software to recover data from a failed SSD?
Free tools can help if the SSD is still readable, but they will not revive a dead controller or damaged firmware. Use them only after you create a clone or image of the drive.
How much does professional SSD data recovery usually cost?
Pricing varies a lot based on the failure type, capacity, plus whether cleanroom or chip-off work is needed. A simple logical recovery is far cheaper than a controller failure that needs board-level repair.
Is it worth opening an SSD to fix it myself?
No, not for most users. Unlike some older drives, an SSD rarely benefits from a home repair, plus opening it will not help with NAND or controller problems.
What is the difference between logical failure and physical failure on an SSD?
Logical failure means the data is there but the file system, partition table, or firmware behavior is broken. Physical failure means hardware inside the SSD has failed, which usually needs specialized recovery tools.
Can TRIM make SSD file recovery impossible?
Yes, TRIM can erase the path to deleted data very quickly, which reduces your chances after a delete or format. If the SSD failed before TRIM had time to run, your odds may be better.
How do I clone a failing SSD before recovery?
Use disk imaging software that can skip bad blocks, then save the image to a healthy drive with enough free space. Work from the clone, not the original SSD, during recovery attempts.
Should I run CHKDSK on a failing SSD?
Usually no, because it can write changes that make recovery harder. If the drive is unstable, imaging it first is safer than letting Windows try to repair the file system.
Can SSD firmware issues be fixed at home?
Sometimes only if the issue is minor, like a compatibility glitch after a power event. For true firmware corruption, recovery labs often need vendor-specific tools that are not available to consumers.
What if my SSD is encrypted with BitLocker?
You will need the BitLocker recovery key before any file recovery can succeed. If the drive still responds, image it first, then unlock the clone with the correct key.
Are there alternatives to data recovery if the SSD is dead?
If the files were backed up to OneDrive, iCloud, Google Drive, or an external disk, restore from there first. For future protection, set up automatic backups plus keep one offline copy.
How can I tell whether my SSD failure is caused by the drive or my computer?
Test the SSD in another computer, another USB enclosure, or a different SATA cable if possible. If it fails the same way everywhere, the SSD itself is the likely problem.
